Agate 5mm NAF Aquatile By NAF Floors@Work

Agate's sound figures are worth reading first. NAF lists IIC 73 for impact noise and STC 72 for airborne sound, helped by a 1.0 mm IXPE underpad. That matters on upper floors, where the people below hear every footstep. Agate is a 5mm NAF Aquatile tile, 304.8 mm by 609.6 mm, with a rigid SPC core, so spills and wet feet are not a concern. The UV lacquer ceramic finish sits over a 0.3 mm wear layer with an AC5 rating, and the edges are painted and microbevelled on four sides. It floats using a Unilin angle click. Rooms kept between 18°C and 29°C suit it, and hydronic radiant heat is fine up to 26 °C. 22FLOORING supplies and installs Agate across Toronto and the GTA, with vinyl installation from $3.20 per square foot.

Structure : Rigid Core Stone Plastic Composite / Sandy Finish

Thickness : 5 mm / 0.19"

Length : 609.6 mm / 24"

Width : 304.8 mm / 12"

Underpad : 1.0 mm IXPE

Impact Sound Reduction (IIC) : 73

Sound Transmission Class (STC) : 72

Click Type : Long Side – Unilin / Short Side – Unilin

Lock System : Angle / Angle Click

Wear Layer : 0.3 mm / 12 mil

Edge Detail : Painted, 4-Sided Microbevelled

Finish : UV Lacquer Ceramic Finish

Rating : AC5

Gloss Level : 5–6%

Texture : Deep Textured

Suitable Location : On, Above, or Below Grade

Radiant Heat : Suitable for Hydronic Systems (up to 26 °C)

Room Temperature Performance : 65°F to 85°F / 18°C to 29°C

Certification : FloorScore Certified

Warranty : 30-Year Residential Ltd. / 5-Year Light Commercial Ltd.
