Bayview 7mm NAF Aquaplus Gold with Underpad By NAF Floors@Work

Bayview installs as a floating floor with no nails. Its drop lock system uses a Unilin profile along its length and 5Gi at the ends, so each row angles in and the ends drop into place. Bayview belongs to NAF Floors@Work's Aquaplus Gold with Underpad family: a 7 mm rigid core vinyl sold with a 1.5 mm HUSSSH underpad made of IXPE. Sound ratings are IIC 78 and STC 74. Planks are 1524 mm (60″) long and 182 mm (7.16″) wide. A 20 mil wear layer, AC5 rating and deep textured finish suit kitchens, hallways and family rooms. Bayview can go on, above or below grade and over hydronic radiant heat. 22FLOORING supplies and installs Bayview across Toronto and the GTA, with vinyl installation from $3.20 per square foot.

Structure: Rigid Core Vinyl w/ HUSSSH! pad
Thickness: 7 mm / 0.27″
Length: 1524 mm / 60″
Width: 182 mm / 7.16″
Underpad: 1.5 mm IXPE (HUSSSH)
Impact Sound Reduction (IIC): 78
Sound Transmission Class (STC): 74
Click Type: Long Side – Unilin / Short Side – 5Gi
Lock System: Drop Lock
Wear Layer: 0.5 mm / 20 mil
Edge Detail: Painted, 4-sided bevelled
Finish: Deep textured
Rating: AC5
Gloss Level: 5–6%
Installation: Floating (no nails)
Suitable Location: On, above, or below grade
Radiant Heat: Suitable for hydronic systems only (up to 26°C)
Room Temperature Performance: 65°F to 85°F / 18°C to 29°C
Certification: FloorScore Certified
Warranty: 30-year residential limited / 5-year light commercial limited
