Bay 7mm NAF AquaSelect By NAF Floors@Work

Bay comes in two box sizes with different click systems: 17.91 sq ft boxes use Valinge 2G on the long side and Valinge 5Gi on the short side, while 15.00 sq ft boxes use I4F on both. Either way it is a drop lock, floating install with no nails. The plank is rigid core vinyl, 7 mm thick, 1524 mm long and 182 mm wide, with a 1.5 mm IXPE pad attached and a 0.5 mm wear layer on the face. The finish is deep textured with painted 4-sided bevels, rated AC5. Sound performance is IIC 78 and STC 73, and it works over hydronic radiant heat up to 26°C. 22FLOORING supplies and installs Bay across Toronto and the GTA, with vinyl installation from $3.20 per square foot.

Structure: Rigid Core Vinyl w/ HUSSSH! pad
Thickness: 7 mm / 0.27″
Length: 1524 mm / 60″
Width: 182 mm / 7.16″
Underpad: 1.5 mm IXPE (HUSSSH)
Impact Sound Reduction (IIC): 78
Sound Transmission Class (STC): 73
Click Type (17.91 sq.ft/box): Long Side – Valinge 2G / Short Side – Valinge 5Gi
Click Type (15.00 sq.ft/box): Long Side – I4F / Short Side – I4F
Lock System: Drop Lock
Wear Layer: 0.5 mm / 20 mil
Edge Detail: Painted, 4-sided bevelled
Finish: Deep textured
Rating: AC5
Gloss Level: 5–6%
Installation: Floating (no nails)
Suitable Location: On, above, or below grade
Radiant Heat: Hydronic systems only (up to 26°C)
Extreme Temperature Performance: 55°F to 95°F / 12°C to 35°C
Certification: FloorScore Certified
Warranty: 30-year residential limited / 5-year commercial limited
