Product Line: SureWood Chevron Luxury Vinyl Flooring
Construction: WPC (Wood Polymer Composite) Vinyl
Dimensions: 8 mm x 305 mm x 718.4 mm
Underlayment: 1.5 mm Antimicrobial Cork Attached
Wear Layer: 0.5 mm (20 mil)
Finish: 2-pass UV Cured Urethane Finish
Installation: Floating Click System (Välinge® 5G)
Residential Warranty: Lifetime
Commercial Warranty: 12 Years
Class: ASTM F1700 Class III, Type B (Embossed)
Slip Resistance: ASTM C1028-07 — Dry: 0.80 / Wet: 0.71
Static Load: ASTM F970 — 1000 psi / Residual Indentation: 0.04 mm
ΔIIC: ASTM E2179-03 — 23
IIC: ASTM E492-09 — 72
STC: ASTM E90-09 — 71
Dimensional Stability: ASTM F2199 — ≤ 0.02 in. per linear foot
Chemical Resistance: ASTM F925 — Not Affected
Abrasion Resistance: ASTM D4060 — 1000 cycles / 0.004% mass loss
Antibacterial Activity: ASTM G21-15 — No Growth Observed
Fire Rating: EN13501-1 — Class Bfl-s1
Critical Radiant Flux: ASTM E648 — > 0.45 watts/cm²
Dibutyl Phthalate (DBP): ISO 16000 — < 1 µg/m³ (28 days)
Diethylhexyl Phthalate (DEHP): ISO 16000 — < 1 µg/m³ (28 days)
Flexibility: EN435 — No Damage
Plank Size: 718.4 mm x 305 mm x 8 mm
Carton Size: 1060 mm x 330 mm x 85 mm
Sq. Ft. per Carton: 23.6
Weight per Carton: 40 lbs
Pallet Size: 1060 mm x 1320 mm x 1035 mm
Volume: 1.45 m³
Cartons per Pallet: 44
Sq. Ft. per Pallet: 1,038.4
Weight per Pallet: 1,790 lbs
